Campervan Insulation Guide: Materials, Methods and Mistakes to Avoid

Insulation is invisible once the walls go up, but it shapes how your van feels every single day. Good insulation keeps heat in during winter, keeps heat out in summer, reduces noise, and helps control condensation. Poor insulation means cold walls, sweaty windows, mould behind panels and a van that turns into an oven in the sun.

This guide explains how insulation works in a vehicle, compares common materials, and walks through a sensible installation process.

How Heat Moves in a Van

Heat moves in three main ways:

• Conduction: through solid materials, such as the metal skin and ribs of the van.
• Convection: through moving air, including draughts and air circulating in wall cavities.
• Radiation: heat from the sun hitting the roof and walls, and heat radiating from your warm body to cold surfaces.

A van is mostly thin steel, which conducts heat very well, plus large glass areas. Insulation slows down these heat flows. No insulation stops heat completely, but good installation can make a dramatic difference.

The Condensation Problem

Warm, moist air from breathing, cooking and drying clothes will condense when it touches a cold surface, just like water droplets on a cold glass. In a van, that cold surface is often the metal skin. If condensation forms inside wall cavities where you cannot see it, it can lead to rust, mould and smells.

There are two main strategies:

1. Keep warm, moist air away from cold metal by filling cavities fully and minimising air gaps.
2. Remove moisture from the air by ventilating well, using a roof fan, and avoiding drying clothes inside.

Ventilation is not optional. Even the best insulation will not prevent condensation in a van with no airflow.

Common Insulation Materials

Below is a general overview. Always read the manufacturer's data sheet, especially regarding fire behaviour, temperature limits and suitability for vehicles.

Closed-Cell Foam Boards (e.g. PIR, XPS)

• Pros: good insulation per thickness, do not absorb much water, easy to cut into flat sheets.
• Cons: rigid, so they do not follow the van's curves; gaps must be sealed. Some products have fire safety concerns, so choose carefully.
• Best for: flat areas such as the roof and large wall panels.

Closed-Cell Foam Sheets (Flexible Rubber Foam)

• Pros: flexible, self-adhesive versions stick directly to the metal, reducing air gaps and condensation risk. Good for curved areas.
• Cons: can be relatively expensive per area, and some adhesives can fail in heat if not applied to clean metal.
• Best for: wheel arches, curved areas, ribs and pillars.

Sheep's Wool

• Pros: natural, pleasant to install, can absorb and release some moisture without losing much insulation value, good sound deadening.
• Cons: must be properly treated against pests; must be fitted so it does not sag; quality varies.
• Best for: filling irregular wall cavities.

Synthetic Fibre Insulation

• Pros: does not absorb water readily, easy to stuff into cavities, does not irritate skin like some mineral wools.
• Cons: must be packed carefully; quality varies between products.
• Best for: cavities and pillars.

Spray Foam

• Pros: fills every gap and bonds to metal, creating a continuous layer.
• Cons: messy, hard to remove, can block drainage channels or wiring routes, and requires protective equipment. Professional application is recommended.

Reflective Foil Bubble Products

• Pros: cheap and easy to fit; reflective layers can help against radiant heat when there is an air gap in front of them.
• Cons: on their own, they provide limited insulation in a van. They should generally be used as a supplement, not the main insulation.

Materials to Avoid

Glass fibre and loose mineral wool can shed irritating fibres, absorb water, and settle with vibration. Many experienced builders avoid them in vans.

Thermal Bridges

The van's metal ribs, pillars and window frames conduct heat straight through your insulation. These are called thermal bridges. Cover them with a thin layer of flexible foam or a similar material before fitting wall battens. This small step greatly reduces cold spots and condensation lines on your panels.

Should You Use a Vapour Barrier?

This is a debated topic among builders. In a house, vapour barriers are carefully designed. In a van, it is very difficult to create a perfect, continuous barrier because of all the screws, cables and openings. A partial barrier can trap moisture rather than stop it.

Many builders now prefer to use materials that do not hold much water (closed-cell foam) or can handle moisture (wool), fill cavities fully, and rely on strong ventilation. Whichever approach you choose, focus on avoiding air gaps against the cold metal.

Step-by-Step Installation

1. Clean and treat the metal. Remove dirt and grease, treat any rust, and let everything dry.
2. Run your wiring first, in conduit, through the cavities. Leave pull cords for future cables.
3. Apply sound deadening (optional) to large flat panels to reduce drumming.
4. Cover ribs and pillars with flexible closed-cell foam to address thermal bridges.
5. Fit boards to large flat areas, cutting them closely and sealing joints with suitable tape.
6. Fill cavities in pillars and irregular areas with wool or synthetic fibre.
7. Insulate the floor with a thin, firm layer to avoid a bouncy floor.
8. Insulate doors, including sliding and rear doors, while keeping drainage holes and mechanisms clear.
9. Fit wall and ceiling battens and panels.

Do not block drain holes in the bottoms of doors and sills; water must be able to escape.

Windows and Cab: The Weak Points

Even a well-insulated body loses lots of heat through glass and the cab. Use insulated window covers, add a curtain or partition between cab and living area, and consider insulated blinds on side windows. In summer, reflective external covers on the windscreen help reduce heat gain.

Insulating for Hot Climates

In the Mediterranean and Middle East, summer heat is often a bigger challenge than winter cold. For hot climates:

• Pay special attention to the roof, which takes the most sun.
• Choose a light-coloured van if possible; dark paint absorbs more heat.
• Use reflective window covers.
• Install a roof fan with both intake and extract functions, and allow cross-ventilation through windows.
• Park in the shade and orient the van to limit sun on the largest windows.

Insulation helps keep the van cooler, but once heat gets in, ventilation is what removes it. See our guide on staying cool in hot weather.

Common Mistakes

1. Leaving air gaps against the metal skin.
2. Forgetting thermal bridges.
3. Using materials that absorb water and stay damp.
4. Blocking drainage channels.
5. Installing insulation before running cables.
6. Skipping ventilation in the belief that good insulation is enough.

Final Thoughts

Insulation is about more than a single material. It is a system: cover thermal bridges, fill cavities without air gaps, handle the weak points like windows and the cab, and ventilate well. Get this stage right and your van will be warmer in winter, cooler in summer, quieter on the road and free from hidden damp. Insulation is Step 7 in our full conversion guide.
